Power Distribution Unit TSU-1040
Technical Specifications
| Item | Specifications |
| 16 way Splitter | |
| Frequency Range | 80~450 MHz |
| Insertion Loss | ≤13.5dB |
| Amplitude Balance | ≤0.3dB |
| Phase Balance | ≤±5° |
| VSWR | 1.5 |
| Isolation | ≥15 |
| Impedance | 50Ω |
| Connectors | N-Female |
| Power Handling | ≤100W |
| Operation Temperature | -10~+40°C |
| Relative Humidity | ≤85% |
| Dimensions | 483*450*132mm |
| Weight | 5kg |
| Marking | CE |
| Standards | EN 61000-6-1,EN 61000-6-3 |
